Yellow IR Ceramic Heater With Thermocouple For Greenhouse

Yellow IR Ceramic Heater With Thermocouple For Greenhouse

 Ceramic IR Heater Emitter

IR Heater Emitter is efficient, robust heaters which provide long wave infrared radiation. They are used in a diverse range of industrial processes such as heaters for thermoforming, and as heaters for paint curing, printing and drying. They are also used very effectively in infrared outdoor heaters and infrared saunas. Most plastics and many other materials absorb infrared wave best in this range, which makes the ceramic heater the most efficient infrared radiant emitter on the market.

Yellow IR Ceramic Heater With Thermocouple For Greenhous

Mean surface temperature383° C400° C488° C535° C563° C670° C

Max permissible operating temperature750° C750° C750° C750° C750° C750° C

Max power density kW/m² ( W/inch²)15 (9.7)18 (11.6)24 (15.5)30 (19.4)36 (23.2)48 (31)

Average weight270 g

Dimensions120*60 mm

Useful wavelength range2 to 10 µm

Applications of IR Heater Emitter:

Infrared Heater Element widely used in vacuum forming, dry food, medical treatment sanitation etc kinds of places of infrared dry firing, solidify etc. It has perfect saving energy effect in electron, textile , light industry, chemical , medicine ,food industry etc, has obvious social profit and economy profit.

Main technical parameter and property:

1.Radiated characteristic: the tiptop single color of radiance of element can reach 0.9

2.Time of heating response: from room temperature to surface temperature of radiated plate, the fixed time will not exceed 20 minutes.

3.Cold and hot resistance: the base body is heated to 800 C and put in cold water repeatly for many times and no cracking. After cold and hot mutual change test for five times, no peel and no craze.

4. The radiated element is heated after electrifying to rating power and immerged into cold water after interruption of power supply for forty times without damage.

5.Good chemical stability; strong causticity-resistance; perfect oxidation-resistance

6.The heating damage of non radiated surface is small.

7. Resistance in common temperature: 1012 ohm 0cm

8.Uneven degree for radiated surface temperature:≤15%

9. Rupture strength for base body: 440Kg/cm2

10.Tolerance of power: ≤5% at rating working voltage

11.Cold state insulated resistance 500V tramegger>2 mΩ

12.Thermal state insulated resistance: 500V tramegger>5 mΩ

13.Using life span: >3000 hours

14.The effect of energy saving is obvious, increasing 10-25% compared with silicon carbide element

15. The life span can prolong more than a few times compared with silicon carbide element.

1. Are you Manufacture or Trade Company?

We are Manufacture for Industrial Heating Element several years.

2.Where is your factory located? How can I visit there?

Our factory is located in Yancheng City(village), Jiangsu Province, China

It takes 4.5 hours by bus ride from Shanghai .Warmly welcome to visit us freely .

3.What type of payment do you have available?

A: TT and L/C

B: West Union,Money gram and Aliexpress are available for sample order .

 4.How can I get some samples?

We are honored to offer you samples .

5.How does your factory do regarding quality control?

Quality without compromise, Laiyuan people always attach great importance to quality controlling from the very beginning to the very end.

Welcome to contact us for more details ,most competitive price for you !
